Disclaimer: Specifications and technical details are for indicative purposes only, subject to change.
CDS can source or manufacture custom cables even if not shown online.
Conductor Material: Bare Copper (Cu.)
Armour Type: Unarmoured
Insulation Material: XLPE
Voltage Rating: 11kV to 33kV
Conductor: Copper, Class 2
Composition: X-90 XLPE, HDS, 5V-90 PVC
Colours: Black
Operating Temp: 90°C
Durability: Moderate resistance to mechanical damage, UV resistant
Flexibility: Fixed
Aus Standards: Complies with AS/NZS1429.1
Industries/Projects: Suitable for applications in dry, indoor, outdoor, underground areas. Limited use when buried directly due to PVC sheath potentially being damaged by high mechanical stress.
