Conductor Material: Bare Copper (Cu.)
Armour Type: Armoured
Insulation Material: PVC
Voltage Rating: 0.6/1 kV
Conductor: Copper, Class 2
Composition: V-90 PVC with Nylon barrier
Colours: Orange
Operating Temp: 90°C
Durability: Galvanised steel wire armoured, High resistance to mechanical damage, UV resistant and Nylon Termite barrier
Flexibility: Fixed
Aus Standards: Complies with AS/NZS 5000.1
Industries/Projects: Suitable for power distribution in industrial and commercial applications where vermin or insect resistance is required, especially for protection from termites. Suitable for direct burial.
