Disclaimer: Specifications and technical details are for indicative purposes only, subject to change.
CDS can source or manufacture custom cables even if not shown online.
Screen Type: Screened
Conductor Material: Bare Copper (Cu.)
Armour Type: Armoured
Voltage Rating: 300V
Conductor: Multi-stranded
Composition: PVC or PUR
Colours: Violet
Operating Temp: -40°C to 80°C
Durability: Type 93 CAN-Bus Cables feature twisted-pair finely stranded copper conductors with a PVC outer jacket, providing reliable mechanical protection and resistance to oils and chemicals in fixed installations. Type 94 cables use a PUR outer jacket for enhanced abrasion resistance, flexibility, and durability under continuous movement and mechanical stress.
Flexibility: Flexible
Aus Standards: Complies with UL Style 2919 (type 93) & 20963, 20549 (type 94)
Industries/Projects: CAN-Bus cables are used for serial communication between control units in automation, automotive, and heavy equipment systems. Common applications include vehicle diagnostics, industrial robotics, conveyor systems, agricultural machinery, and marine electronics—where reliable, noise-resistant data transmission is essential for real-time control and system coordination.
